OPERATION
AUGER TRANSPORT
POSITION
IMPORTANT:
Fill auger should always be
secured for transport, no matter
how short the distance.
1
1. Position the auger so that the
tube is resting on the locking
mechanism at the back of the
tank and the discharge spout is
hanging freely. 1 FIG 7.
FIG. 7
2. The locking mechanism must be
use when transporting at all
times.
1 FIG 8.
1
FIG. 8
NOTE: It is easier to move the
auger when on level ground.
.
2. Push the auger diverter valve
back to the fan position. FIG 9.
FIG. 9
