Manual Calibration Guide
5
Procedure:
Step 1: Having Selected Meter
(1, 2 or 3) Calibration, “Target
10.0lb/ac” is displayed. Press
the Toggle Button or Enter
Key.
Enter your desired “target”
application rate by using the
Toggle Button and Selector
Knob to edit. Once the desired
target application rate is set,
press the Toggle Button or
Enter Key to accept. In the
example below “Target” is set
for 100lb/ac.
Measure and record the weight
of the empty calibration bucket.
Remove the plate on the bottom
of the meter and place the
calibration bucket under the
meter as shown. Turn the
diverter valve to the lower air
stream position for calibration
(return to proper position after
calibration is complete).
Calibration Bucket Weight:
