Model RS30 Hazardous Duty Metallic Page 5
Dimensions: Hazardous Duty RS30 Metallic ANSI Style Flange Connections
K
P
AIR INLET
1" NPT
A
F
G
H
J
B
C
D
E
DISCHARGE PORT
3" ANSI STYLE CONNECTION
1" NPT HIGH FLOW
EXHAUST MUFFLER
SUCTION PORT
3" ANSI STYLE
CONNECTION
M
L
N
Q
BOTH SUCTION AND DISCHARGE PORTS ARE
AVAILABLE WITH 3" DIN STYLE CONNECTIONS
English
.125
Metric
3mm
Alumin
um
Cast
Iron
Stainles
s
Alloy
"C"
Aluminum
Cast Iron
Stainless
Alloy "C"
A
4.13
4.25
105
108
B
18.93
19.06
481
484
C
31.75
32.00
806
813
D
35.69
35.82
906
910
E
17.94
18.07
456
460
F
4.19
95
G
12.46
316
H
12.81
325
J
26.31
668
K
19.65
499
L
10.13
257
M
12.00
305
N
11.75
299
P
.52
.69
13
18
Q
.62
16
