Model RS30 Hazardous Duty Metallic Page 2
Check
Diaphragm/
Check
Non-Wetted
Shipping
MODEL
Pump
Pump
Valve
Design
Wetted
Check Valve
Valve
Material
Porting
Pump
Pump
Kit
Weight
Brand
Size Type Level Material Materials Seat Options Options Style Options
Options
lbs.
(kg)
RS30B1ABBANASX0
RS
30
B
1
A
B
B
A
N
A
S
X0
148 (67)
RS30B1AEEANASX0
RS
30
B
1
A
E
E
A
N
A
S
X0
148 (67)
RS30B1AGTANASX0
RS
30
B
1
A
G
T
A
N
A
S
X0
148 (67)
RS30B1ANNANASX0
RS
30
B
1
A
N
N
A
N
A
S
X0
148 (67)
RS30B1A1EANASX0
RS
30
B
1
A
1
E
A
N
A
S
X0
148 (67)
RS30B1IBBANASX0
RS
30
B
1
I
B
B
A
N
A
S
X0
247 (112)
RS30B1IEEANASX0
RS
30
B
1
I
E
E
A
N
A
S
X0
247 (112)
RS30B1IGTANASX0
RS
30
B
1
I
G
T
A
N
A
S
X0
247 (112)
RS30B1INNANASX0
RS
30
B
1
I
N
N
A
N
A
S
X0
247 (112)
RS30B1I1EANASX0
RS
30
B
1
I
1
E
A
N
A
S
X0
247 (112)
RS30B1SBBANASX0
RS
30
B
1
S
B
B
A
N
A
S
X0
226 (103)
RS30B1SGTANASX0
RS
30
B
1
S
G
T
A
N
A
S
X0
226 (103)
RS30B1SNNANASX0
RS
30
B
1
S
N
N
A
N
A
S
X0
226 (103)
RS30B1S1EANASX0
RS
30
B
1
S
1
E
A
N
A
S
X0
226 (103)
RS30B1HGTANASX0
RS
30
B
1
H
G
T
A
N
A
S
X0
267 (121)
Pump Brand
RS= SANDPIPER
®
AirVantage
Pump Size
30 = 3"
Check Valve Type
B = Ball
Design Level
1 = Design Level
Wetted Material
A = Aluminum
I = Cast Iron
S = Stainless Steel
H = Alloy C
Diaphragm Check Valve Materials
1 = Santoprene/Santoprene
2 = PTFE-Santoprene/PTFE
B = Nitrile/Nitrile
C = FKM/PTFE
E = EPDM/EPDM
I = EPDM/Santoprene
G = PTFE-Neoprene/PTFE
N = Neoprene/Neoprene
Check Valve Seat
A = Aluminum
B = Nitrile
C = Carbon Steel
E = EPDM
N = Neoprene
S = Stainless Steel
T = PTFE
V = FKM
Non-Wetted Material Options
A = Painted Aluminum
J = Painted Aluminum w/PTFE
Coated Hardware
Y = Painted Aluminum with
Stainless Steel Hardware
Porting Options
N = NPT Threads
B = BSP (Tapered) Threads
A = ANSI Flange
D = DIN Flange
R = Raised Face 150#
Threaded ANSI Flange
Pump Style
A = Anodized Aluminum
Air Saving Valve
Pump Options
S = Self-Contained Electrical
Generation with High Flow
Metal Muffler
Kit Options
X0= EST ATEX Compliant
X1= ATEX, Intrinsically-Safe 5-30VDC,
110/120VAC, 220/240VAC Pulse
Output
Kit
Y0= EST US Hazardous Duty
Y1= US Hazardous Duty, Intrinsically-
Safe 5-30VDC, 110/120VAC,
220/240VAC Pulse Output Kit
Note: Models listed in the table are for reference only. See nomenclature below for other models.
Explanation of Pump Nomenclature, Hazardous Duty RS30 Metallic • Design Level 1 • Ball Valve
