rs30nmdl2sm-rev0614 Model RS30 Non-Metallic Page 2
Pump Brand
RS= SANDPIPER ®
Pump Size
30= 3"
Check Valve Type
B= Ball
Design Level
2= Design Level 2
Wetted Material
K= PVDF
P= Polypropylene
Diaphragm Check Valve Materials
1= Santoprene/Santoprene
2= PTFE-Santoprene Backup/PTFE
Check Valve Seat
K= PVDF
P= Polypropylene
U= Polyurethane/ Polyurethane
Non-Wetted Material Options
A= Painted Aluminum
J= Painted Aluminum PTFE
Q= Epoxy Coated Aluminum
Porting Options
A= ANSI Flange
D= DIN Flange
7= Dual Porting (ANSI)
8= Top Dual Porting (ANSI)
9= Bottom Dual Porting (ANSI)
Pump Options
S= Self-Contained Electrical
Generation with High Flow
Metal Muffler
Pump Style
A = Anodized Aluminum Air
Saving Valve
Kit Options
00.= None
P0.= 10-30VDC Pulse Output Kit
P1.= Intrinsically-Safe
5-30VDC,110/120VAC,
220/240VAC Pulse Output Kit
P2.= 110/120 or 220/240VAC
Pulse Output Kit
RS30 Non-Metallic · Design Level 1· Ball Valve
Explanation of Pump Nomenclature
Check Diaphragm/ Check Non-Wetted Shipping
MODEL Pump Pump Valve Design Wetted Check Valve Valve Material Porting Pump Pump Kit Weight
Brand Size Type Level Material Materials Seat Options Options Style Options Options lbs. (kg)
RS30B2P1PQAAS00. S 30 B 2 P 1 P Q A A S 00. 231 (105)
RS30B2P2PQAAS00. S 30 B 2 P 2 P Q A A S 00. 231 (105)
RS30B2K1KQAAS00. S 30 B 2 K 1 K Q A A S 00. 315 (143)
RS30B2K2KQAAS00. S 30 B 2 K 2 K Q A A S 00. 315 (143)
