rs30nmdl2sm-rev0614

Model RS30 Non-Metallic Page 15

Dual Port Option Drawing

3" ANSI STYLE FLANGE CONNECTION

FOUR ø.75 HOLES ON A ø6.00 BOLT CIRCLE

3" ANSI STYLE FLANGE CONNECTION

FOUR ø.75 HOLES ON A ø6.00 BOLT CIRCLE
