set1dl3sm-rev0614 Model SET1 Type 3 Page 11
* Available only in kit form. Order 031-060-000 which
includes Items 7, 8, 9, 24 and 25.
ITEM TOTAL
NO. PART NO. DESCRIPTION RQD.
40 518-076-110 Manifold, Discharge 1
41 312-052-111 Elbow, Suction 2
42 312-051-111 Elbow, Discharge 2
43 361-005-600 Gasket Seal, Suction 2
44 361-006-600 Gasket Seal, Discharge 2
45 200-032-115 Clamp, Suction 2
46 200-033-115 Clamp, Discharge 2
47 542-002-114 Stud Nut 4
48 542-011-000 Stud Nut Assembly 16
49 542-004-000 Stud Nut Assembly 12
50 170-044-115 Capscrew, Hex Head 4
51 900-004-115 Washer, Lock 4
52 545-004-115 Hex Nut 4
53 618-003-110 Pipe Plug 1
54 312-044-555 45° Elbow 1
55 538-025-555 Nipple, Pipe 1
56 530-018-000 Muffler, Exhaust 1
57 780-027-025 Spring 1
58 807-048-115 Stud 2
59 286-040-604 Diaphragm 2
60 196-077-600 Chamber, Driver 2
61 618-025-110 Boss Plug 4
61-A 560-078-611 O-Ring 4
Not Shown:
031-030-000 Valve Body Assembly 1
Includes Items 1,2,3,4,5, & 57
535-015-000 Name Plate 1
705-002-000 Screw, Drive 4
Repair Parts shown in bold face
(darker) type are more likely to need
replacement after extended periods
of normal use. The pump owner may
prefer to maintain a limited inventory of
these parts in his own stock to reduce
repair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
