SANDPIPER SET1 - Manual (Page 11)

Model SET1 Type 3 Page 10 set1dl3sm-rev0614
REPAIR PARTS LIST AND DRAWING
Sanitary Type 3
1 095-051-558 Body, Spool Valve 1
2 031-039-000 Sleeve & Spool Set 1
3 560-058-360 O-Ring 8
4 165-038-558 Cap, End 2
5 675-043-115 Ring, Retaining 2
6 165-042-332 Cap, Valve Body 1
7 360-056-360 Gasket 1
8 360-057-360 Gasket 1
9 360-058-360 Gasket 1
10 095-074-001 Pilot Valve Body Assembly* 1
10-A 095-071-557 Pilot Valve Body 1
10-B 755-025-000 Sleeve (with O-Ring) 1
10-C 560-033-360 O-Ring (Sleeve) 4
10-D 775-014-000 Spool (with O-Ring) 1
10-E 560-023-360 O-Ring (Spool) 4
10-F 675-037-080 Retaining Ring 1
11 170-063-115 Capscrew, Hex Head 1
12 901-035-115 Washer, Flat 7
13 542-001-115 Nut, Square 1
14 170-033-115 Capscrew, Hex Head 4
15 901-005-115 Washer, Flat 4
16 170-043-115 Capscrew, Hex Head 6
17 114-011-332 Bracket, Intermediate 1
18 196-066-332 Chamber, Inner 1
19 196-064-332 Chamber, Inner 1
20 560-040-360 O-Ring 2
21 560-001-360 O-Ring 2
22 135-013-162 Bushing 2
23 675-042-115 Ring, Retainer 2
24 620-007-114 Plunger, Actuator 2
25 132-022-360 Bumper 2
26 070-012-170 Bearing, Sleeve 2
27 720-010-375 Seal, U-Cup 2
28 196-065-111 Chamber, Outer 2
29 901-012-180 Washer, Sealing 2
30 115-078-115 Bracket, Foot 1
31 675-040-360 Ring, Sealing 2
32 685-039-120 Rod, Diaphragm 1
33 132-019-360 Bumper 2
34 612-101-111 Plate, Outer Diaphragm 2
35 612-022-330 Plate, Inner Diaphragm 2
36 286-008-366 Diaphragm 2
286-008-368 Diaphragm 2
37 722-045-600 Seat, Valve 4
38 050-024-600 Ball, Check Valve 4
39 518-077-110 Manifold, Suction 1
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
Model SET1
Original Instructions
