47
Appendix A Setting Up Static IP Address
12. Enter the following numbers in the “Subnet mask” text box:
255.255.255.0
Do not include the periods; they are automatically entered.
13. Enter the following numbers in the “Default gateway” text box:
192.168.0.1
Do not include the periods; they are automatically entered.
14. Activate the “Use the following DNS server addresses” circle by clicking in it.
15. Enter the following numbers in the “Preferred DNS server” text box:
192.168.0.1
Do not include the periods; they are automatically entered.
16. Click
OK
. The “Internet Protocol (
TCP/IP
) Properties” window disappears.
17. In the “Local Area Connection Properties” window, click
OK
. The Local Area
Connection Properties window disappears.
18. Click Close in the Local Area Connection Status window. The window disap-
pears.
19. Close the Network and Dial-up Connections window by clicking on the “x”
button at the upper right corner of the window.
The computer is now set up with a static
IP
address, allowing the user to access the
Modem’s Advanced Setup utility.
