SANDPIPER S15 Metallic - Manual (Page 23)

SOLENOID SHIFTED AIR VALVE PARTS LIST
(Includes all items used on Composite Repair Parts List except as shown)
Item Part Number Description Qty
38 893-097-000 Solenoid Valve, NEMA4 1
39 219-001-000 Solenoid Coil, 24VDC 1
219-004-000 Solenoid Coil, 24VAC/12VDC 1
219-002-000 Solenoid Coil, 120VAC 1
219-003-000 Solenoid Coil, 240VAC 1
40 241-001-000 Connector, conduit 1
241-003-000 Conduit Connector with 1
Suppression Diode (DC Only)
41 170-029-330 Capscrew, Hex HD 5/16-18 x 1.50 4
42 618-051-150 Plug 2
For ATEX Compliant Solenoid Coils used in the European Union
39 219-011-001 Solenoid Coil, Single mounting 12 VDC, 3.3W / 267mA 1
219-011-002 Solenoid Coil, Single mounting 24 VDC, 3.3W / 136mA 1
219-011-003 Solenoid Coil, Single mounting 110/120 VAC, 3.4W / 29mA 1
219-011-004 Solenoid Coil, Single mounting 220/240 VAC, 3.4W / 15mA 1
Note: Item 35 (Conduit Connector) is not required
Declaration of Conformity
Signature of authorized person Date of issue
Printed name of authorized person
Revision Level: F
Title
David Roseberry Engineering Manager
October 20, 2005
Date of revision
August 23, 2012
Manufacturer: Warren Rupp, Inc. ® , 800 N. Main Street
Mansfield, Ohio, 44902 USA
Certifies that Air-Operated Double Diaphragm Pump Series: HDB, HDF, M Non-Metallic,
S Non-Metallic, M Metallic, S Metallic, T Series, G Series, U Series, EH and SH High Pressure,
RS Series, W Series, SMA and SPA Submersibles, and Tranquilizer Surge Suppressors comply with
the European Community Directive 2006/42/EC on Machinery, according to Annex VIII.
This product has used Harmonized Standard EN809:1998+A1:2009, Pumps and Pump Units
for Liquids - Common Safety Requirements, to verify conformance.
Written Warranty
5 - YEAR Limited Product Warranty
Quality System ISO 9001 Certified • Environmental Management Systems ISO 14001 Certified
Warren Rupp, Inc. (“Warren Rupp”) warrants to the original end-use purchaser that no product sold by
Warren Rupp that bears a Warren Rupp brand shall fail under normal use and service due to a defect in material
or workmanship within five years from the date of shipment from Warren Rupp’s factory. Warren Rupp brands
include SANDPIPER®, MARATHON®, PortaPump®, SludgeMaster™ and Tranquilizer®.
~ See complete warranty at sandpiperpump.com/content/warranty-certifications ~
7: W
ARRANTY
