• Model SA1/SA25
Explanation of Pump Nomenclature
ATEX Detail
Wet End Materials
B Nitrile
N Neoprene
R Hytrel
S Santoprene
V FKM
E EPDM
Design Level
5
Construction
A Aluminum Wetted, Aluminum Air
SI Stainless Steel Wetted, Cast Iron Air
SS Stainless Steel Wetted, Aluminum Air
Options
P1 Intrinsically Safe ATEX Compliant
Pulse Output
Pump Series
S SANDPIPER ®
Pump Design
A Flap
Pump Size
1 1"
25 1" BSPT (Tapered Thread)
Discharge Porting Position
D Bottom
ET Dual Top
T Top
ED Dual Bottom
Your Serial #:
(fill in from pump nameplate)
_____________________________________
__ __ _____ __ ___ __ __ __
Pump Pump Pump Size
Options
Discharge Diaphragm/ Design Construction
Series Design and Options Porting Valve Level
Model #:
(fill in from pump
nameplate)
Your Model #:
II 1G c T5
II 3/1 G c T5
II 1D c T100°C
I M1 c
I M2 c
II 2GD T5
(1) Models equipped with Construction designations
SI or HI. Note: See ATEX Explanation of Type
Certificate
II 2G c T5
II 3/2 G c T5
II 2D c T100°C
Models equipped with Construction designations A,
SI, SS, HC, or HI. Note: See ATEX Explanation of
Type Examination Certificate
II 2GD T5
Note: Pumps ordered with the options listed in (1) to the left are
ATEX compliant when ordered with kit option P1.
II 2G Ex ia c IIC T5
II 2D c iaD 20 IP67 T100˚C
(2) II 2G Ex ia c IIC T5
II 3/2 G Ex ia c IIC T5
II 2D Ex c ia 20 IP67
T100°C
XX X XXXXXX, X XX XXX X XX
MODEL SPECIFIC
1: PUMP
SPECS
