• Model SA1/SA25
Composite Repair Parts List
Item
Part Number
Description
Qty
1
031.030.557
Assembly, air valve
(cast iron centers only)
1
031.203.000
Assembly, air valve
2
070.012.170
Bearing, sleeve
2
3
095.074.001
Pilot valve assembly
1
4
114.007.157
Bracket, intermediate
1
114.012.010
Bracket, intermediate
(cast iron centers only)
1
5
115.070.330
Bracket, mounting (top porting only)
1
115.071.330
Bracket, mounting
(bottom porting only)
1
6 132.019.360 Bumper
2
7
132.022.360
Bumper, actuator
2
8
135.034.506
Bushing, plunger
2
9
165.134.157
Assembly, air inlet cap
1
165.134.558
Assembly, air inlet cap
(cast iron centers only)
1
10
170.029.330
Capscrew, hex head 5/16-18 x 1.50
16
11
170.006.330
Capscrew, hex head 5/16-18 x .88
(Cast iron centers)
6
170.032.330
Capscrew, hex head 1/4-20 x 1.00
6
12
170.045.330
Capscrew, hex head 5/16-18 x 1.25
4
13
170.063.330
Capscrew, hex head 1/4-20 x 1.75
1
14
170.033.330
Capscrew, hex head 3/8-16 x 3.25
(Cast iron centers)
4
170.083.330
Capscrew, hex head 3/8-16 x 3.75
4
15
171.010.330
Capscrew, hex flange 3/8-16 x 1.75
4
16
196.012.110
Chamber, outer
2
196.012.157
Chamber, outer
2
17
196.042.157
Chamber, inner
1
196.090.010
Chamber, inner (cast iron centers only)
1
18
196.043.157
Chamber, inner
1
196.084.010
Chamber, inner (cast iron centers only)
1
19
286.008.354
Diaphragm (santoprene)
2
286.008.356
Diaphragm (hytrel)
2
286.008.360
Diaphragm (nitrile)
2
286.008.363
Diaphragm (fkm)
2
286.008.364
Diaphragm (epdm)
2
286.008.365
Diaphragm (neoprene)
2
20
334.013.110
Flange, porting (1" npt)
2
334.013.110 E
flange, porting (1" bsp tapered)
2
334.013.157
Flange, porting (1" npt)
2
334.013.157 E
flange, porting (1" bsp tapered)
2
334.036.110
Flange, dual porting (1" npt)
2
334.036.110 E
flange, dual porting (1" bsp tapered)
2
334.036.156
Flange, dual porting (1" npt)
2
334.036.156 E
flange, dual porting (1" bsp tapered)
2
21
338.007.360
Valve, flap (nitrile)
2
338.007.363
Valve, flap (fkm)
2
338.007.364
Valve, flap (epdm)
2
338.007.365
Valve, flap (neoprene)
2
22
350.002.360
Foot, rubber
4
23
360.030.425
Gasket, manifold
2
360.030.600
Gasket, manifold
2
24
360.031.379
Gasket, flange (conductive nitrile)
2
360.031.384
Gasket, flange (conductive neoprene)
2
360.031.608
Gasket, flange (conductive ptfe)
2
Item
Part Number
Description
Qty
25
360.056.379
Gasket, pilot valve (conductive nitrile)
1
26
360.057.360
Gasket, air valve body (nitrile)
1
27
360.058.360
Gasket, air inlet (nitrile)
1
28 518.015.110 Manifold
1
518.015.156 Manifold
1
29
530.036.000
Muffler
1
30
542.001.330
Nut, square 1/4-20
1
31
545.004.330
Nut, hex 5/16-18
32
32
545.005.330
Nut, hex 3/8-16
4
33
547.002.330
Nut, stop
4
34 560.001.360 O-ring
2
35 560.040.360 O-ring
2
36
612.022.330
Plate, inner diaphragm
2
37
612.101.110
Assembly, outer diaphragm plate
2
612.108.157
Assembly, outer diaphragm plate
2
38
618.003.330
Plug, pipe 1/4 npt
3
39
618.003.110
Plug, pipe 1/4 npt
(used in outer chambers)
2
618.003.330
Plug, pipe 1/4 npt
(used in outer chambers)
2
40
620.007.114
Plunger, actuator
2
41
675.040.360
Ring, sealing
(not used on cast iron centers)
2
42
675.042.115
Ring, retaining
2
43
685.039.120
Rod, diaphragm
1
44
706.013.330
Screw, machine
4
45
720.010.375
Seal, u-cup
2
46
722.021.360
Seat, flap valve (nitrile)
2
722.021.363
Seat, flap valve (fkm)
2
722.021.364
Seat, flap valve (epdm)
2
722.021.365
Seat, flap valve (neoprene)
2
47
807.029.330
Stud 5/16-18
12
48
900.004.330
Washer, lock 5/16
16
49
900.005.330
Washer, lock 3/8
6
50
901.005.330
Washer, flat 3/8
4
51
901.012.180
Washer, copper sealing
2
52
901.035.330
Washer, flat 1/4
7
901.035.330
Washer, flat 1/4
(cast iron centers only)
1
53
905.001.015
Washer, taper
4
54
255.012.335
Coupling, pipe 1" npt
(Polypropylene air valve only)
1
55
312.017.335
Elbow, 90 degree
(top ported option cast iron only)
1
312.123.162
Elbow, 90 3/4 npt
(top ported option only)
1
ATEX Compliant
LEGEND:
= Items contained within Air End Kits
= Items contianed within Wet End Kits
Note: Kits contain components specific to the material codes.
MODEL SPECIFIC
3: EXP
VIEW
