SANDPIPER SB25 - Manual (Page 3)

sb1dl5sm-rev0714
sandpiperpump
.
com Model SB1/SB25
Table of Contents
SECTION 1: PUMP SPECIFICATIONS ................1
• Explanation of Nomenclature
• Performance
• Materials
• Dimensional Drawings
SECTION 2: INSTALLATION & OPERATION ......5
• Principle of Pump Operation
• Recommended Installation Guide
• Troubleshooting Guide
SECTION 3: EXPLODED VIEW ...........................8
• Composite Repair Parts Drawing
• Composite Repair Parts List
• Material Codes
SECTION 4: AIR END .......................................11
• Air Valve Assembly for Aluminum Center Sections
• Air Valve Assembly for Cast Iron Center Sections
• Pilot Valve Assembly
SECTION 5: WET END .....................................15
• Diaphragm Drawings
• Diaphragm Servicing
SECTION 6: OPTIONAL CONFIGURATIONS ....17
• Dual Port
SECTION 7: WARRANTY & CERTIFICATES ....19
• Warranty
• EC Declaration of Conformity - Machinery
• EC Declaration of Conformity - ATEX
• EC Summary of Markings
MODEL SPECIFIC
1: PUMP
SPECS
2: INST
AL
& OP
3: EXP
VIEW
4: AIR
END
5: WET END
6: OPTIONAL
7: W
ARRANTY
