Page 12: Exp view
sb1dl5sm-rev0714
sandpiperpump
.
com
9
• Model SB1 & SB25
Item
Part Number
Description
Qty.
22
286.015.604
DIAPHRAGM, OVERLAY
2
23
334.013.110
FLANGE, THREADED PORTING (1" NPT) 2
334.013.110E
FLANGE, THREADED PORTING (1" BSP) 2
334.013.112
FLANGE, THREADED PORTING (1" NPT) 2
334.013.112E
FLANGE, THREADED PORTING (1" BSP) 2
334.013.157
FLANGE, THREADED PORTING (1" NPT) 2
334.013.157E
FLANGE, THREADED PORTING (1" BSP) 2
24
350.002.360
FOOT, RUBBER
4
25
360.057.360
GASKET
1
26
360.056.379
GASKET
1
27
360.058.360
GASKET
1
28
360.030.425
GASKET, MANIFOLD
2
360.030.600
GASKET, MANIFOLD
2
29
360.115.379
GASKET, FLANGE
4
360.115.384
GASKET, FLANGE
4
360.115.608
GASKET, FLANGE
4
30
518.006.156
MANIFOLD
1
518.006.110
MANIFOLD
1
518.006.112
MANIFOLD
1
31
530.036.000
MUFFLER
1
32
542.001.330
NUT, SQUARE
1
33
545.004.330
NUT, HEX, 5/16-18
26
34
545.005.330
NUT, HEX, 3/8-16
4
35
547.002.330
NUT, STOP
4
36
560.001.360
O-RING
2
37
560.040.360
O-RING
2
38
612.022.330
PLATE, DIAPHRAGM, INNER
2
612.218.330
PLATE, DIAPHRAGM, INNER
(USE WITH ONE-PIECE
BONDED DIAPHRAGM)
2
39
612.101.110
ASSEMBLY, OUTER DIAPHRAGM PLATE 2
612.101.112
ASSEMBLY, OUTER DIAPHRAGM PLATE 2
612.108.157
ASSEMBLY, OUTER DIAPHRAGM PLATE 2
40
618.003.330
PLUG, PIPE, 1/4
3
41
620.007.114
PLUNGER, ACTUATOR
2
42
675.040.360
RING, SEALING
2
43
675.042.115
RING, RETAINING
2
44
685.039.120
ROD, DIAPHRAGM
1
45
706.013.330
SCREW, MACHINE
4
46
720.010.375
SEAL, U-CUP
2
47
722.026.580
SEAT, CHECK VALVE
2
722.102.110
SEAT, CHECK VALVE
2
722.102.112
SEAT, CHECK VALVE
2
48
900.004.330
WASHER, LOCK - 5/16
10
49
901.005.330
WASHER, FLAT, 3/8
4
50
901.012.180
WASHER, SEALING
2
51
901.035.330
WASHER, FLAT, 1/4
7
901.035.330
WASHER, FLAT, 1/4
(CAST IRON CENTERS ONLY)
1
52
900.005.330
WASHER, LOCK, 3/8
6
53
905.001.015
WASHER, TAPER
4
54
255.012.335
COUPLING, PIPE, 3/4 NPT
(CAST IRON CENTERS ONLY)
1
58
618.003.110
PLUG, PIPE
(STAINLESS STEEL ONLY)
2
618.003.112
PLUG, PIPE
(ALLOY C ONLY)
2
618.003.330
PLUG, PIPE
(ALUMINUM ONLY)
2
Composite Repair Parts List
ATEX Compliant
LEGEND:
= Items contained within Air End Kits
= Items contianed within Wet End Kits
Note: Kits contain components specific to the material codes.
Item
Part Number
Description
Qty.
1
031.203.000
ASSEMBLY, MAIN AIR VALVE
1
031.030.557
ASSEMBLY, AIR VALVE
(CAST IRON CENTERS ONLY)
1
2
050.008.365
BALL, CHECK
4
050.008.354
BALL, CHECK
4
050.008.356
BALL, CHECK
4
050.008.360
BALL, CHECK
4
050.008.363
BALL, CHECK
4
050.011.600
BALL, CHECK
4
3
070.012.170
BEARING, SLEEVE
2
4
095.074.001
PILOT VALVE ASSEMBLY
1
5
114.007.157
INTERMEDIATE
1
114.012.010
BRACKET, INTERMEDIATE
(CAST IRON CENTERS ONLY)
1
6
115.071.330
BRACKET, MOUNTING
1
7
132.019.360
BUMPER
2
8
132.022.360
BUMPER, ACTUATOR
2
9
135.034.506
BUSHING, PLUNGER
2
10
165.042.157
CAP, AIR INLET, ASS'Y
1
165.042.558
CAP, AIR INLET, ASS'Y
(CAST IRON CENTERS ONLY)
1
11
170.029.330
CAPSCREW, HEX HD,
5/16-18 X 1.50
16
12
170.043.330
CAPSCREW, HEX HD,
1/4-20 X 1.00
6
170.006.330
CAPSCREW, HEX HD,
5/16-18 X 7/8
(CAST IRON CENTERS ONLY)
6
13
170.083.330
CAPSCREW, HEX HD,
3/8-16 UNC X 3.75
4
170.033.330
CAPSCREW, HEX HD,
3/8-16 UNC X 3.25
(CAST IRON CENTERS ONLY)
4
14
170.045.330
CAPSCREW, HEX HD,
5/16-18 X 1 1/4
4
15
170.122.330
CAPSCREW, HEX HD,
5/16-18 X 5.00
6
16
170.063.330
CAPSCREW, HEX HD,
1/4-20 X 1.75
1
17
171.010.330
CAPSCREW, FLANGE LOCK,
3/8-16 UNC X 1.75
4
18
196.012.157
CHAMBER
2
196.012.110
CHAMBER, OUTER
2
196.012.112
CHAMBER, OUTER
2
19
196.042.157
CHAMBER, INNER
1
196.084.010
CHAMBER, INNER
(CAST IRON CENTERS ONLY)
1
20
196.043.157
CHAMBER, INNER
1
196.090.010
CHAMBER, INNER
(CAST IRON CENTERS ONLY)
1
21
286.008.354
DIAPHRAGM
2
286.008.356
DIAPHRAGM
2
286.008.360
DIAPHRAGM
2
286.008.363
DIAPHRAGM
2
286.008.364
DIAPHRAGM
2
286.008.365
DIAPHRAGM
2
286.008.366
DIAPHRAGM
2
286.112.000
DIAPHRAGM, ONE-PIECE BONDED
2
UNIVERSAL ALL SP
3: EXP
VIEW
