Getting to Know Your Lathe
Tools Required for Assembly
Item Description
Phillips Screwdriver
Adjustable Wrench
6
A. Stand Leg
B. Stand Body
C. Lathe Bed
D. Tailstock locking lever
E. Tailstock handwheel
F. Tail stock
G. Tailstock spindle locking arm
H. Live center
I. Tool rest base
J. Tool rest
K. Tool rest seat locking lever
L. Spur center
M. Face plate
N. Spindle lock
O. Motor
P. Belt tensioning lever
Q. Headstock locking lever
R. Switch
F
K
B
D
E
H G
A
C
I
J
L
M
N
O
P
Q
R
