70-425
20”
18”
37”
1.5HP, 1Ph, 110/220V
6
320,440,730,1180,2230,2930 RPM
1-1/4” x 8
MT2
MT2
3/8”
3-15/16”
64-1/2”(L)x21-1/2”(W)x50”(H)
461 lbs
Model Number
Swing Over Bed
Swing Over Tool Rest Base
Working Distance Between Centers
Motor
Speeds
Speed Ranges
Spindle Nose in x TPI
Headstock Taper
Tailstock Taper
Hole Through Spindle
Ram Travel
Overall Dimensions
Net Weight
Table of Contents
Safety Warnings............................................................................................................................................2-3
Lathe Safety Rules................................................................................................................................... ............ 3
Specifications.............................................................................................................................................4
Unpacking and Contents........................................................................................................................... .5
Getting to Know Your Lathe..........................................................................................................................6
Assembly.................................................................................................................................................... 7
Determine Lathe Location in Workshop................................................................................................ .7
Bolting Lathe to the Stand..........................................................................................................................7
Adjustments................................................................................................................................................8
Attaching the Live Center.............................................................................................................................8
Swiveling the Headstock......................................................................................................9
Tightening or Loosening the Headstock..............................................................................................9
Changing Spindle Speeds....................................................................................................................................9
Adjusting the Tool Rest..........................................................................................................................................9
Adjusting the Tailstock...........................................................................................................................................9
Variable Speed Switch..................................................................................................................................................10
Indexing /Spindle Lock........................................................................................................................................10
Electrical Requirements......................................................................................................................................11
Wiring Diagram......................................................................................................................................11
Troubleshooting........................................................................................................................................12
Explosion Diagrams..........................................................................................................................................13-14
Parts Lists.............................................................................................................................................................15-16
Warranty..................................................................................................................................................17
Specifications
