CHOOSE YOUR SPRAYER,
BEGIN WITH THE BOOM!
Gaspardo has always worked to meet the needs of every customer: in the new sprayer
range this philosophy has been followed with the possibility to choose from many
different booms on four basic models.
MECHANICAL BOOMS
BDL boom
BDL boom is made for simpler
machines, the manual opening has
a spring dampened hinge. Working
widths up to 10 m are available,
with very compact configuration
and low centre of mass when
closed. It is available as a further
simplified version: BDL light.
START boom
Hydraulic folding boom for SAuro
model, 2 cylinders make easy of
12 or 14 m boom opening. Self-
levelling with automatic lock is a
standard feature. Manual lifting is
available upon demand.
NOVA 122 boom
Is a fully mechanical boom with
rear “X” closing available on SAuro
and GIoVE models. noVA working
width is 12 m and is available
with or without the mechanical
self-levelling system; a manual
reel-lifter with safety device can
be installed upon demand.
“WORK X” and “WORK U” booms
Work series is made by 2 models with hydraulic folding: in transport
configuration the two booms can have vertical or cross rear closing. Self-
levelling is standard on both as the 1000 mm hydraulic lifting; it is available
optionally with dampened suspension.
PROBO boom
The mechanical boom for GIoVE
sprayer: rear horizontal closing
and upwards-folding ends. Manual
reel-lifting (1000 mm) is a standard
feature on both working widths (12
and 14 m)
HYDRAULIC BOOMS
8
MOUNTED SPRAYERS
