ONE-PIECE HEADSTOCK
VERTICAL LEVELLING
The plough’s opera ng angle can be
manually set adjus ng two screws placed
on each side of the headstock. The beams
should be adjusted at 90° to the ground.
FRONT FURROW WITH ADJUSTMENT
Front furrow width can be adjusted manually
or hydraulically ac ng on the slide block
guide. By the hydraulic system, fi rst body
furrow width can be adapted directly from
the cab and it is very prac cal when working
on slopes with highly variable ground. For
on-furrow ploughs the slide block is available
with length up to 1000 mm.
WELL SUPPORTED
Heat treated turnover sha with tapered
roller bearings is fi ed precisely into
the beam. The turnover axel has a Ø of
90 (S versions) 100 (M versions), 120
(L versions) and 130 mm (XL and XXL
versions).
EASY MATCHING
Fixed or oscilla ng heavy-duty 3-point
hitch made by heat treated steel is placed
downward in order to maximize the weight
distribu on and trac on. All headstocks
have oblong holes for a aching the upper
connec ng rod; these holes allow to follow
uneven grounds maintaining consistent the
working depth.
