5.14 Miscellaneous Setup - Hidden Channel
12
The system provides a function to hide a
channel in monitoring mode. The selected
channel can still be recorded while it’s hidden;
the hidden picture is viewable during playing
back.
Press [SEL] to select a channel to hide.
MISCELLANEOUS SETUP
CHANGE PASSWORD
SET TIME
HIDDEN CHANNEL
AUDIO PORT SETUP
PTZ SETUP
IMAGE PARAMETERS
PASSWORD ENABLE
KEYPAD TONES
SEQ.DWELL TIME
VGA SETUP
( )MOVE (SEL)SELECT (MENU)EXIT
[ 4 ]
[ CH4 ]
[ OFF ]
[ ON ]
[OFF ]
1024*768 60HZ
5.15 Miscellaneous Setup - Audio Port Setup
5.16 Miscellaneous Setup - PTZ Setup
Press [SEL] to select the camera, press[◄◄] and [►►] buttons to assign the ID.
Note: the ID must be unique．
You can select the audio recording
function to ON or OFF, and select the
video channel that you like to record the
audio on.
SPEED: Set the baud rate (2400，4800，
9600，19200，38400) to match your speed
dome.
PROTOCOL: Supports “PELCO-D” and
“PELCO-P”. Select the protocol according to
your speed dome’s protocol.
CAMERA: select the camera channel which
is connected with the speed dome.
ID: Assign an ID to your speed dome.
PTZ SETUP
SPEED [4800]
PROTOCOL [PELCO-D]
CAMERA- [ 1 ] ID [ 1 ]
( )MOVE ( )CAM ID
(SEL)SELECT (MENU)EXIT
AUDIO PORT SETUP
AUDIO PORT1-VIDEIO CHANNEL
AUDIO PORT1-RECORD
( )MOVE (SEL)SELECT (MENU)EXIT
[ 1 ]
[ OFF ]
