MULTI-TASKER™
400-0362-003 20
2: SAVE (Card Settings)
In1-Out1 ON
In1-Out2 ON
In1-Out3 ON
In1-Out4 ON
In1-Out5 ON
In1-Out6 ON
In1-Out7 ON
SAVE THIS SETTING?
1: YES
2: NO
KEY=
3: CLEAR (Set to Defaults)
RESET CARD TO FACTORY DEFAULT:
* All Outputs: Connected To Input1
* All Outputs: Turned On
1: YES
2: NO
KEY=
4: ON/OFF (Turn Outputs On/Off)
TOGGLE ON/OFF: ENTER A NUMBER
0: All OFF
1: Out1 (ON)
2: Out2 (ON)
3: Out3 (ON)
4: Out4 (ON)
5: Out5 (ON)
6: Out6 (ON)
7: Out7 (ON)
9: All ON
ESC: GO BACK; S:STATUS
KEY=
5: IN-OUT (Switch I/O Connection)
SWITCH IN-OUT: ENTER A NUMBER
In1-Out1 ON
In7-Out2 ON
In1-Out3 ON
In1-Out4 ON
In1-Out5 ON
In1-Out6 ON
In1-Out7 ON
ESC: GO BACK; S:STATUS
In
2: SETUP
1: SET GROUP ID
CURRENT GROUP ID: NONE
1: ASSIGN GROUP ID
ASSIGN GROUP ID: ENTER NUMBER
1: Group 1
2: Group 2
3: Group 3
4: Group 4
5: Group 5
6: Group 6
7: Group 7
8: Group 8
ESC: GO BACK
KEY=
2: REMOVE GROUP ID
REMOVE GROUP ID: ENTER NO
ESC: GO BACK
KEY=
ESC: GO BACK
KEY=
2: SET MATRIX CONFIG
CURRENT MATRIX: NOT APPLICABLE
ESC: GO BACK
KEY=
3: SET SYNC DELAY
SELECT OUTPUT: ENTER NUMBER
1: SDL1=00 (00.00 Sec)
2: SDL2=00 (00.00 Sec)
3: SDL3=00 (00.00 Sec)
4: SDL4=00 (00.00 Sec)
5: SDL5=00 (00.00 Sec)
6: SDL6=00 (00.00 Sec)
7: SDL7=00 (00.00 Sec)
8: SDL8=00 (00.00 Sec)
ESC: GO BACK
KEY=
ESC: GO BACK
KEY=
