Altinex MT105-120/121 - Manual (Page 13)

MULTI-TASKER™
400-0362-003 12
Command Format: [SIGOmCnUi]
m = Output (m = # from 1 to max outputs)
Cn = Card ID (n = # from 1 to max slots)
Ui = Unit ID (i = # from 0 to 9)
Example 1:
The card in slot #4 has Input 1 connected to
Output 1 and Output 1 is turned ON. Verify the
output signal is detected by sending the
command [SIGO1C4] and receiving feedback
equal to "1".
10. [ON]
This command will enable one or more outputs
for a single card, or a group of cards.
SINGLE CARD OPERATION
Command Format: [ONmCnUi]
m = Output (m = # from 1 to max outputs)
Cn = Card ID (n = # from 1 to max slots)
Ui = Unit ID (i = # from 0 to 9)
Example:
There is an MT105-120 card in slot #5. All of
the outputs on the card are OFF.
1) [ON1C5]: Turns ON only Output 1 of the
MT105-120 card.
2) [ON12C5]: Turns ON Outputs 1 and 2.
3) [ONC5]: Turns ON all Outputs.
GROUP OPERATION
Command Format: [ONmGkUi]
This command enables Output "m" for each
card in group "k" of unit "i".
m = Output (m = # from 1 to max outputs)
Gk = Group number (k = # from 1-8)
Ui = Unit ID (i = # from 0-9)
Example:
[ON1G1]: Turns ON Output 1 for each card in
Group 1. See the GROUP commands for a
detailed explanation.
PATH OPERATION
This command will set the path for the output,
but it is not active until the switch command,
[SW], is executed. Commands ending in "P" are
not executed immediately. The path for outputs
on multiple cards or the same card may be
preloaded.
Command Format: [ONmCnUiP]
m = Output (m = # from 1 to max outputs)
Cn = Card ID (n = slot # from 1 to max slots)
Ui = Unit ID (i = # from 0 to 9)
P = Path
Example:
There are two MT105-120 cards in slots 6 and
7. Enable Output 1 of card 6 and Output 3 of
card 7 simultaneously. To do this, send the
following commands:
[ON1C6P]
[ON3C7P]
[SW]
If "F" is included, use the [ONmCnPF]
command or the [ONmCnFP]
command.
FEEDBACK OPERATION
After processing a command, an OK or ER will
be returned as feedback if "F" is included at the
end of a command string.
Command Format: [ON…..F]
Example:
[ON1C2F]: if path is not set
[ON1C2PF]: if path is set
