11. [OFF]
This command disables one or more outputs for
a single card or a group of cards.
SINGLE CARD OPERATION
Command Format: [OFFmCnUi]
m = Output (m = # from 1 to max outputs)
Cn = Card ID (n = # from 1 to max slots)
Ui = Unit ID (i = # from 0 to 9)
Example:
Card 5 has Output 1 ON. The following
commands may be used to turn OFF the
output.
1) [OFF1C5]: Turns OFF Output 1 only.
2) [OFF23C5]: Turns OFF Outputs 2 and 3.
3) [OFFC5]: Turns OFF all outputs.
GROUP OPERATION
Command Format: [OFFmGkUi]
This command disables output "m" for each
card in group "k" of unit "i".
m = Output (m = # from 1 to max outputs)
Gk = Group ID (k = # from 1-8)
Ui = Unit ID (i = # from 0-9)
Example:
1. [OFF1G1]: Turns OFF Output 1 for each
card in group 1.
2. [OFFG1]: Turns OFF all outputs for each
card in group 1.
PATH OPERATION
Command Format: [OFFmCnUiP]
This command will set the path for the output,
but it is not active until the switch command,
[SW], is executed. Commands ending in "P" are
not executed immediately. The path for outputs
on multiple cards or the same card may be
preloaded.
m = Output (m = # from 1 to max outputs)
Cn = Card ID (n = # from 1 to max slots)
Ui = Unit ID (i = # from 0 to 9)
P = Path
Example:
There are two MT105-120 cards in slots 6 and
7. Disable Output 1 of card 6 and Output 3 of
card 7 simultaneously using the following
commands:
[OFF1C6P]
[OFF3C7P]
[SW]
If "F" is included, use the [OFFmCnPF]
command or the [OFFmCnFP]
command.
FEEDBACK OPERATION
Command Format: [OFF…..F]
After processing a command, an OK or ER will
be returned as feedback if "F" is included at the
end of a command string.
Example:
[OFF1C2F]: if path is not set
[OFF1C2PF]: if path is set
12. […S] – SAVE
This command will save the configuration
command being sent in memory. When
sending the command [I1O1C4S], after reset or
power up, Input 1 will be connected to Output 1
on C4. This command only saves the Input 1 to
Output 1 connection above. In order to save all
the current settings, use the [CnS] command.
13. […F] – FEEDBACK
After processing a command, an OK or ER will
be returned as feedback if "F" is included at the
end of a command string.
