MULTI-TASKER™
400-0362-003 16
Command Format: [WRCn
1
Cn
2
…GkUi]
Cn = Card ID (n = slot # from 1 to max slots)
Gk = Group number (k = # from 1-8)
Ui = Unit ID (i = # from 0-9)
Example:
To group cards 1, 2, and 3 as group 5 of
Unit ID
1, send the command
[WRC1C2C3G5U1]. After executing this
command, cards 1, 2 and 3 will be grouped
together as group 5 of Unit ID 1. The system
will return the following feedback:
G1=C1C2C3
Now, when a command is sent to G1, each
board in G1 will execute the same command.
22. [RMC]
This command may be used to remove one or
more group members from a group.
Command Format: [RMCn
1
Cn
2
…GkUi]
Cn = Card ID (n= # from 1 to max slots)
Gk = Group number (k = # from 1-8)
Ui = Unit ID (i = # from 0-9)
Example:
Group 1 consists of the cards located in slots
numbered 1, 2, 3, 4 and 5. Remove just cards
#4 and #5 from the group by sending the
command [RMC4C5G1]. The system will return
the following feedback:
G1=C1C2C3
23. [RMG]
This command may be used to delete an entire
group, or all groups.
REMOVE ONE GROUP MEMBERS
Remove all the members from the group,
effectively deleting the group.
Command Format: [RMGkUi]
Gk = Group number (k = # from 1-8)
Ui = Unit ID (i = # from 0-9)
Example:
Group 1 consists of the cards located in slots
number 1, 2 and 3. Remove all cards from the
group by sending the command [RMG1]. The
system will return the following feedback:
G1=EMPTY
REMOVE ALL GROUPS
Remove all the members from every group,
effectively deleting all groups.
Command Format: [RMG [Ui]
Ui = Unit ID (i = # from 0-9)
Example:
Group 1 consists of cards 1 and 2. Group 2
consists of cards 1, 2, 3, 4 and 5. Delete all the
groups by sending the command [RMG
[]. The
system will return the following feedback:
G1-G8:EMPTY
24. [RD]
This command reads and then displays the
members in each group.
Command Format: [RDGkUi]
Gk = Group number (k = # from 1-8)
Ui = Unit ID (i = # from 0-9)
Example:
The cards in slots 1, 2 and 19 are part of
group 5. Read the member data for group 5, by
sending the command [RDG5]. The system will
return feedback as follows:
G1=C1C2C19
The feedback shows G1 (Group 1) and then the
cards that make up Group 1. In this case,
Group 1 includes C1, C2 and C19.
