B-2 OPERATION B-2
DESIGN FEATURES AND ADVANTAGES
FOR STICK WELDING
•
Excellent DC constant current output for stick weld-
ing applications.
• Continuous adjustment of both voltage and current
for unsurpassed welds on demanding jobs.
• Remote control capability standard.
FOR AUXILIARY POWER
• 3,000 watts of 115/230 VAC, 60 Hz auxiliary power.
• One 20 amp 115 VAC duplex receptacle for up to 26
amps of 115 VAC power.
• One 15 amp, 230 VAC duplex receptacle for up to 13
amps of 230 VAC power.
• Weld and AC auxiliary power at the same time (with-
in the limits shown on the chart below).
OTHER FEATURES
•
Perkins 4-cylinder, water cooled diesel engine.
Designed for long life, easy maintenance and excel-
lent fuel economy.
• Engine protection system shuts the engine down for
low engine oil pressure or high coolant temperature.
• Electronic Engine Idler. Engine automatically goes to
low idle in 10 to 14 seconds after welding or use of
auxiliary power stops. Includes high idle switch.
• Gauges for engine oil pressure, coolant temperature
and battery charging ammeter.
• Engine hour meter standard.
• Extended range 22.5 gallon (85.1 L) fuel tank.
DUTY CYCLE
Duty cycle is based on a ten minute period and opera-
tion in an ambient temperature of 104
° F(40 ° C).
The SAE-400 SEVERE DUTY IS NEMA rated at 60%
duty cycle. Duty cycle is based on a ten minute period.
Therefore, a 60% duty cycle welder can be operated at
nameplate rated output for 6 minutes out of every 10
minute period without overheating.
The auxiliary power can be used continuously (100%
duty cycle) within its rated current capacities.
SAE-400 SEVERE DUTY
Welding Using Only Using Only Total
Current, Amps 115V Circuit, 230V Circuit, Aux.
@ NEMA Arc Amps Amps kVA
Volts
0 26 13 3.0
100 19.5 9.75 2.25
200 13 6.5 1.5
300 6.5 3.25 0.75
400 0 0 0
