E-5 TROUBLESHOOTING E-5
DC655e (CE) (RED-D-ARC)
Observe all Safety Guidelines detailed througout this manual
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your
Local Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
CAUTION
PROBLEMS
PROBLEMS
(SYMPTOMS)
POSSIBLE
CAUSE
RECOMMENDED
COURSE OF ACTION
Machine will not weld. OCV is less
than 1 volt.
The wire feeder will not come on.
Poor arc characteristics.
1. The machine may be in a over-
load condition. Refer to Machine
Protection in the operation sec-
tion.
2. See the PC board LED informa-
tion.
1. Either the 42VAC or the 115VAC
circuit breakers may be tripped.
Reset if necessary.
2. Check for the presence of the
required voltage to operate the
wire feeder.
3. The control cable or wire feeder
may be faulty.
1. The negative welding cable may
be connected to the wrong induc-
tance tap.
2. Make sure the mode switch is in
the proper position for the
process.
3. The control board may be faulty.
See PC board LED information.
Contact your Local Authorized Field
Service
Facility for technical
troubleshooting assistance.
