Python Owner's Manual - page 18
Water Cooled Lead Assy*
This Power Cable has a Boot
that is common to many
assemblies but must be
removed from this end
when used on the Python.
*Leads shown for reference only
226 Series Water Cooled Cable Assemblies
Length Conduit #4 Power/
Water Cable
Control Cable Gas Hose Water
Hose
Snake
Skin ®
15'/4.5m 615-0601-15 001-2521 005-0690 001-0537 001-0529 931-0110
25'/7.6 615-0601-25 001-2524 005-0691 001-0538 001-0530 931-0122
50'/15.2m 615-0601-50 843-0338 005-0692 001-0665 001-0667 931-0123
This Power Cable has a Boot
that is common to many
assemblies but must be
removed from this end
when used on the Python.
TORQUE REQUIRES
100+5 IN-LB
