Lincoln Electric IM624 LTA 2.0 TELESCOPIC EXTRACTION ARM - Manual (Page 21)

Recommended Spare Parts are Highlighted in Bold
1 Elastic Band, 8” S23282-1 4 X
2 Rotating Hinge, LTA S23282-7 1 X
3 Arm Section, LTA S23282-8 1 X
4 Replacement Hose Section, 4 ft. S23282-12 2 X
5 Airflow Valve Control Knob S23282-4 1 X
6 Hood Assembly S23282-5 1 X
7 Plastic Friction Plug S23282-6 1 X
8 Telescopic Guide S23282-9 1 X
5-28-99
FUME EXTRACTION ARMS
Use only the parts marked “x” in the column under the
heading number called for in the model index page. # Indicates a change this printing.
P-320-D.1
ITEM DESCRIPTION PART NO. QTY. 1 2 3 4 5 6 7 8 9
P-320-D.1
