B-4 DIMENSION PRINTS
LN-10 / ZIPLINE BOOM PACKAGE
B-4
16 FT. HYDRAULIC ZIPLINE BOOM ASSEMBLY
(4 PLACES)
HOLE
FOR 3/4" BOLTING
.81
14.00
TYP.
.81
12.38
12.38
60.00
48.00
17.38
7.75
38.25
52.25
.81
(16'-0")
N.A.
N.B. PALLET BASE IS OPTIONAL. AVAILABLE SIZES ARE N.A. BOOM ADJUSTS FROM THE HORIZONTAL POSTION
UPWARD 50 TO DOWNWARD 18. 46" X 48" OR 60" X 60".
5.00
46.00
60.00
33.00
45.00
N.B.
211.6 (17'-8")
192.0
XA
181.0 (15'-1")
16.45
83.13
TYP.
(16'-0") R 192.0
MAST PEDESTAL DETAIL
14.00
15.00
