Installation – Lincoln Electric IM596-2 LN-10_ZIPLINE BOOM PACKAGE User Manual
Page 10
A-6
INSTALLATION
LN-10 / ZIPLINE BOOM PACKAGE
A-6
FRONT VIEW
LN-10 CONTROL BOX ASSEMBLY
MOUNTING SLOTS
REINSTALL
COVER AFTER
CONNECTIONS
ARE MADE
CONNECT
ELECTRODE
WELD CABLE
TO WIRE FEEDER
HERE
CONNECT
ELECTRODE
WELD CABLE
FROM POWER
SOURCE HERE
MOUNTING SLOT
CONNECT
POWER INPUT
CONTROL CABLE
FROM POWER
SOURCE HERE
CONNECT
CONTROL CABLE
ASSEMBLY TO WIRE
FEEDER HERE
