GRAPHIC SYMBOLS THAT APPEAR
ON THIS MACHINE OR IN THIS
MANUAL
Output Control 1 Single Phase
Remote Control Setting 3 Three Phase
Local Control Settin U o Rated No-Load Voltage
Input Power Type U
1
Rated Input Voltage
Submerged Arc Welding U
2
Rated Welding Voltage
Transformer Type X Rated Duty Cycle
Fuse I
1
Rated Input Current
High Voltage Indicator I 2 Rated Welding Current
High Temperature Indicator
Rated Frequency
B-1 OPERATION
IDEALARC ® AC-1500
B-1
ELECTRIC SHOCK
can kill.
• Do not touch electrically live parts
or electrode with skin or wet
clothing.
• Insulate yourself from work and
ground.
• Always wear dry insulating
gloves.
FUMES AND GASES
can be dangerous.
• Keep your head out of fumes.
• Use ventilation or exhaust to
remove fumes from breathing
zone.
WELDING SPARKS
can cause fire or
explosion
• Keep flammable material away.
• Do not weld on containers that
have held combustibles.
ARC RAYS
can burn.
• Wear eye, ear and body
protection.
SAFETY PRECAUTIONS
Read and understand this entire section before oper-
ating the machine.
Observe additional Safety Guidelines detailed
throughout this manual.
WARNING
