TECHNICAL SPECIFICATIONS – CLASSIC 300G (K1754-1)
CLASSIC 300G
A-1 INSTALLATION A-1
DC CURRENT RANGE
Fine Adjustment in each Range
40-350 Amps
DUTY CYCLE
100%
60%
RATED DC OUTPUT*
VOLTS @ RATED AMPS
30V @ 250A
NEMA Rating
32V @ 300A
(1) 115V will operate either 60 Hz. or 50/60 Hz. power tools, lights etc.
* Based on a 10 min. period.
Make/Model Description Speed (RPM) Displacement Ignition Capacities
cu. in. (Ltrs.) System
High Idle 1800 Delco Voyager Fuel: 15 gal.
4 Cylinder High Energy 57 Ltrs.
GM 4 Cycle
3.0 Liter Water-Cooled Full Load 1800 Distributor Type Oil: 4.5 Qts.
Gasoline Engine 4.3 Ltrs.
Classic 300G Cast Iron Cylinder 183.0(3.0) Electronic
(K1754-1) Block/Crankcase Low Idle 1360
53.0 HP @
1800 RPM
INPUT - GASOLINE ENGINE
RATED OUTPUT - WELDER
HEIGHT WIDTH DEPTH WEIGHT
40.94** in. 24.00 in. 66.91in.
1039.9 mm 609.6 mm 1700 mm 1330 lbs. (603kg.)
**Top of enclosure, add 8.0” (203.2mm) for exhaust
OUTPUT - GENERATOR
Auxiliary Power 1
3000 Watts, 60 Hz. AC
(26 Amps @ 115V), (13 Amps @ 230V)
PHYSICAL DIMENSIONS
ENGINE OPERATING LOAD FUEL CONSUMPTION
Cooling 9.9 Qts.
9.4 Ltrs.
DESCRIPTION
300 Amp DC Welder
All Copper Windings
Pure DC Power
Generator
Low Idle (1360 RPM)-No Load
High Idle (1800 RPM)-No Load
AC Auxiliary-115 Volts-26 Amps
50 Amps @ 22 Volts @ 60% Duty Cycle
100 Amps @ 24 Volts @ 60 % Duty Cycle
150 Amps @ 26 Volts @ 60% Duty Cycle
200 Amps @ 28 Volts @ 60 % Duty Cycle
250 Amps @ 30 Volts @ 60 % Duty Cycle
300 Amps @ 32 Volts @ 60 % Duty Cycle
250 Amps @ 30 Volts @ 100 % Duty Cycle
.89 gal/hr (3.37 ltrs/hr)
1.32 gal/hr (5.00 ltrs/hr)
1.42 gal/hr (5.32 ltrs/hr)
1.24 gal/hr (4.70 ltrs/hr)
1.27 gal/hr (4.82 ltrs/hr)
1.33 gal/hr (5.04 ltrs/hr)
1.47 gal/hr (5.57 ltrs/hr)
1.66 gal/hr (6.27 ltrs/hr)
1.83 gal/hr (6.91 ltrs/hr)
2.15 gal/hr (8.12 ltrs/hr)
