E-3 E-3 TROUBLESHOOTING
PROBLEMS
(SYMPTOMS)
Poor arc striking with electrode
sticking or blasting off.
POSSIBLE AREAS OF
MISADJUSTMENT(S)
1. Make sure settings for wire feed
speed and voltage are correct
for process being used.
2. The Run-In (Fast or Slow) speed
may be wrong for process and
technique being used. See
Operation Section.
3. The gas shielding may be
improper for process being used.
RECOMMENDED
COURSE OF ACTION
If all recommended possible areas
of misadjustment have been
checked and the problem persists,
Contact your local Authorized
Field Service Facility.
OUTPUT PROBLEMS
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your
LOCAL AUTHORIZED FIELD SERVICE FACILITY for assistance before you proceed.
CAUTION
PROBLEMS
(SYMPTOMS)
Rough wire feeding or wire will not
feed but drive rolls are turning.
The wire feed stops while welding.
When trigger is released and pulled
again the wire feed starts.
POSSIBLE AREAS OF
MISADJUSTMENT(S)
1. The gun cable may be kinked or twisted.
2. The wire may be jammed in the gun
cable, or gun cable may be dirty.
3. Check drive roll tension and
position of grooves.
4. Check for worn or loose drive rolls.
5. The electrode may be rusty or dirty.
6. Check for damaged or incorrect
contact tip.
7. Check wire spindle for ease of
rotation and adjust break ten-
sion knob if necessary.
1. Check the wire feed drive rolls
and motor for smooth operation.
2. Check for restrictions in the wire
feed path. Check the gun and
cable for restrictions.
3. Make sure gun liner and tip are
correct for wire size being used.
4. Make sure drive rolls and guide plates
are clean and are the correct size.
5. If K1701-1 Timer Option Kit is
installed, make sure the spot timer
knob is set to off.
6. Check spindle for ease of rotation.
RECOMMENDED
COURSE OF ACTION
If all recommended possible areas
of misadjustment have been
checked and the problem persists,
Contact your local Authorized
Field Service Facility.
FEEDING PROBLEMS
PM 255
Observe all Safety Guidelines detailed throughout this manual
