A-1 INSTALLATION
INVERTEC V275-S
A-1
Height Width Depth Weight (With Cord)
13.6in.(345mm) - Handle Folded Down 20.25 in.(514mm)
9.0 in.(229mm) 54.5lbs. (24.7Kg)
16in.(406mm) - Handle Up 21.7 in.(551)-With Cord Strain Relief
PHYSICAL DIMENSIONS
THREE PHASE SINGLE PHASE
RECOMMENDED MINIMUM INPUT WIRE AND FUSE SIZES
Input Voltage-Hz
208/230-60
460/575-60
220-50
380/400/415-50
440-50
Fuse Size
(Time Delay Fuse)
Amps
60
35
60
35
35
Cord Size AWG(mm 2 )
based on a type S, SJ, SJO
or SJT Flexible cord
in 30°C Ambient
8(8.4)
14(2.5)
8(8.4)
12(4)
14(2.5)
(1) When operating on these inputs, the line cord may need to be changed
* On 208VAC Single Phase the 35% duty cycle output rating is 275A @ 29V
Technical Specifications - Invertec V275-S
INPUT AT RATED OUTPUT - THREE PHASE ONLY
INPUT VOLTS-Hz
208/230/460/575V - 60Hz
220/380/400/415/440 - 50Hz
INPUT
CURRENT
AMPS
27/25/13/11
34/33/17/14
38/37/19/16
25/15/15/14/13
32/20/19/18/17
IDLE
POWER
150W Max
IDLE
POWER
150W Max
EFFICIENCY
@ RATED
OUTPUT
87%
EFFICIENCY
@ RATED
OUTPUT
87%
OUTPUT
CONDITIONS
[email protected]%
250A@30V. 60%
275A@31V. 35%
[email protected]%
250A@30V. 35%
INPUT AT RATED OUTPUT - SINGLE PHASE ONLY
INPUT VOLTS-Hz
208/230/460/575V - 60Hz
220/380/400/415/440 - 50Hz
INPUT
CURRENT
AMPS
49/48/26/21
63/62/33/27
68/67/38/31
48/32/30/29/27
63/42/40/38/36
OUTPUT
CONDITIONS
[email protected]%
250A@30V. 60%
275A@31V.* 35%
[email protected]%
250A@30V. 35%
OUTPUT (THREE AND SINGLE PHASE)
Input Voltage-Hz
208-60
230-60
460/575-60
220-50
380/400/415-50
440-50
Cord Size AWG(mm 2 )
based on a type S, SJ, SJO
or SJT Flexible cord
in 30°C Ambient
6(16) 1
6 (16) 1
10 (6)
6(16) 1
8(10)
10(6)
Fuse Size
(Time Delay Fuse)
Amps
100
100
60
100
60
60
TEMPERATURE RANGES
OPERATING TEMPERATURE RANGE
-20°C to +40°C
STORAGE TEMPERATURE RANGE
-40°C to +40°C
WELDING NO LOAD
CURRENT RANGE VOLTAGE
5-275 Amps 70 VDC
