Maintenance – Lincoln Electric IM802 INVERTEC V275-S User Manual
Page 18
D-3
MAINTENANCE
D-3
INVERTEC V275-S
FIGURE D.2 — LOCATION OF MAINTENANCE COMPONENTS.
SWITCH BOARD &
HEAT SINK ASSEMBLY
CONTROL PC BOARD
MAIN TRANSFORMER ASSEMBLY
CHOKE ASSEMBLY
OUTPUT TERMINALS
POWER SWITCH
CENTER ASSEMBLY
INPUT
RECTIFIER
COOLING FANS
CASE BACK ASSEMBLY
CASE FRONT ASSEMBLY
WRAP-AROUND
BASE
OUTPUT
RECTIFIER
ASSEMBLY
