Frequency (vpm) 4300（72Hz）
Compaction depth
(cm)
30(12in)
Travel speed (cm/s) 28(11in/s)
Efficiency (m
2
/hr) 400(4300ft
2
/hr)
Plate Size (cm) 62Ч40(24Ч16in)
Working Dimension
(cm)
120Ч40Ч93(47Ч16Ч37in)
Drive Belt: 1× ”B” section vee belt
Acoustic Noise ( According to 2000/14/EC)
Hand-Arm-Vibration ( as per ISO8662, part 1, m/s2):4-9
TRANSPORTATION
1. Always shut off engine when transporting machine.
2. Make sure lifting device has enough capacity to hold machine ( see identification plate on machine
for weight).
3. Use central lifting point (a) (c) (as optional) when lifting machine.
4. Trolley wheel (b) as optional is used for short distance transportation.
TROUBLE SHOOTING
SYMPTOM POSSIBLE CAUSES SOLUTION
Travel Speed too low,
and vibration is weak
Engine speed too low? Set engine speed to correct RPM.
Clutch slips? Check or replace clutch
V- belt slips? Adjust or replace V-belt
Excessive oil in vibration? Drain excess oil and fill to proper lever
Malfunction in vibrator housing? Check eccentric, gears and counter weights
Bearing Failure? Replace Bearing
Insufficient engine output? Check engine, compression, etc.
ENGINE TROUBLE SHOOTING
SYMPTOM POSSIBLE CAUSES SOLUTION
Difficult to start, ”Fuel
is available, but no
Spark plugs bridging? Check gap, insulation or replace spark
plug.
Carbon deposit on spark plug? Clean or replace spark plug.
Model No. KPC160W
Measured Sound Power Level 101.5dB
Guaranteed sound power level 104.50dB
Uncertainly 3dB
