Johnson Level & Tool Mfg. 40-6543 - Manual (Page 15)

9. Technical Specifications
Laser Wavelength 532nm±10nm
Laser Classification Class IIIa
Maximum Power Output ≤ 5mW
Accuracy ±1/8"/100 ft. (±1mm/10m)
Interior Range Up to 400 ft. (120m) diameter depending
upon light conditions
Exterior Range Up to 1,200 ft. (400m) diameter with
detector (not included)
Remote Range Up to 200 ft. (60m) diameter
Self-Leveling Range ±3.5°
Power Supply NiMH rechargeable battery pack, 6.4V
adapter (included)
4 “C” alkaline batteries (not included)
Battery Life Approx. battery life 16 hours continuous use
(rechargeable battery pack); 15 hours with
alkaline batteries
Dimensions 7.087" x 6.378" x 7.953"
(180 x 162 x 202mm)
Weight 4.409lbs (2kg)
Working Temperature 32°F to 104°F (0°C to +40°C)
Center screw thread 5/8" – 11
Scanning Modes 0, 30º, 60º
Rotation Speed 150, 200, 250, 300 rpm
IP Protection Class 66
©2013 Johnson Level & Tool - Rev. 1 15
