©2010 Johnson Level & Tool - Rev. 2 7
Special Base
6. Operating Instructions
Battery Installation
Note: Always check to be sure that the on/off switch
is in the off position before removing and replacing
batteries.
1. Open the battery-box cover and put in three “AA”
batteries according to the illustrated polarity direction
2. Place the instrument on a platform or a tripod.
3. Power on the instrument by turning the on/off
switch to the on position, and a cross line will be
projected.
Bracket
Magnet
Mounting
Belt Groove
1/4" – 20 thread
Instrument
Connecting
Knob
5/8" thread
Rubber
Magnet
IMPORTANT: It is the responsibility of the user to verify the
calibration of the instrument before each use.
