2 ©2010 Johnson Level & Tool - Rev. 2
Table of Contents
1. Kit Contents
2. Features and Functions
3. Safety Instructions
4. Location/Content
of Warning Labels
5. Location of Parts/Components
6. Operating Instructions
7. Using the Product
8. Self-Check & Fine Calibration
9. Technical Specifications
10. Application Demonstrations
11. Care and Handling
12. Product Warranty
13. Warranty Registration
14. Accessories
1. Kit Contents
Description for Model 40-6620 and 40-6625 Qty.
Self-Leveling Cross Line Laser Level 1
Multi-Functional Magnetic Base 1
“AA” Alkaline Batteries 3
Mounting Strap 1
Magnetic Target 1
Instruction Manual with Warranty Card 1
Soft Sided Pouch 1
2. Features and Functions
• Able to project one cross-line beam, consisting of one horizontal line
and one vertical line.
• Magnetic dampening compensation system.
• Laser flashes/sounds audible alarm when beyond leveling range.
• Manual mode feature allows unit to be tipped at extreme angles
without the audible alarm and laser flash being triggered
• Multi-functional magnetic base is included to allow
hanging on wall, attach to metal, or connect to tripod
(5/8"-11 or 1/4"-20).
• Includes adjustable strap for attachment to pipe or conduit.
