12 ©2010 Johnson Level & Tool - Rev. 2
9. Technical Specifications
Laser Wavelength 635nm±10
Laser Classification Class II (40-6620)
Class IIIa (40-6625)
Maximum Power Output ≤ 1mW (40-6620) ≤5mW (40-6625)
Accuracy ±1/8"/35 ft. (±3mm/10m)
Interior Range Up to 100 ft. (30m) depending upon light
conditions (40-6620)
Up to 150 ft. (45m) depending upon light
conditions (40-6625)
Self-Leveling Range ± 5°
Power Supply 3 “AA” alkaline batteries
Battery Life Approx. battery life 20 hours continuous use
Dimensions 2" x 5-1/4" x 6-1/4" (51x133x159mm)
Weight 2 lbs. (0.93 Kg)
Working Temperature 14°F to 113°F (-10°C to +45°C)
Center Screw Thread 5/8" – 11; 1/4" – 20
IP Protection Class 55
