3.
General remarks
3.1.
Technical data
Type
2 G 40 / 2 G 40 H
Design
Air-cooled four-stroke diesel engine
Combustion system
Direct injection
Number of cylinders
2
Bore/stroke
mm
92 / 75
Displacement
cm³
997
Engine oil content
2.5 excl. sump
1)
incl. filter renewal
l. approx.
3.0 incl. sump
1)
Difference between
„max“ and „min“ levels
l. approx.
0.8
1)
Engine oil pressure
min.
1 bar at 900 r.p.m. engine speed
Engine oil consumption
(after running-in period)
approx.
1% of fuel consumption at full load
Direction of rotation,
power take-off end
anti-clockwise
Valve clearances at 10 - 30 °C
Inlet/exhaust
mm
0.10
Max. permissible perm. inclination
Exhaust
Flywheel
Angle of inclination in °
low high
low high
without oil sump
30
2)
17
2)
25
2)
25
2)
with oil sump
30
2)
17
2)
30
2)
25
2)
Weight (incl. fuel tank, air-cleaner,
kg
exhaust silencer and electric starter)
approx.
106
Battery capacity
min / max
12 V - 45 / 88 Ah • 24 V - 36 / 55 Ah
1)
These values are intended as an approximate guide. The max. marking on the dipstick is the
determining factor, Fig. 6.
2)
Exceeding these limits causes engine breakdown.
