30
CPU Feature (Press Enter)
Scroll to this item and press to view the following screen, and the
following items are only available when the motherboard supports Prescott
CPU; however, when the motherboard doesn’t support Prescott CPU, the
items of TM2 Bus Ratio, TM2 Bus VID and Limit CPUID MaxVal will not be
available.
Phoenix – AwardBIOS CMOS Setup Utility
CPU Feature
Item Help
Thermal Management [Thermal Monitor 1]
TM2 Bus Ratio [0 X]
TM2 Bus VID [0.8375V]
Limit CPUID MaxVal [Disabled]
Menu Level
Thermal Monitor 1 (On die
throtting)
Thermal Monitor 2 Ratio &
VID transition
↑ ↓ → ← : Move Enter : Select +/-/PU/PD:Value: F10: Save ESC: Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Thermal Management (Thermal Monitor 1)
This item sets CPU’s thermal control rule to protect CPU from overheat. This
feature is only available when CPU supports Thermal Monitor 2.
TM2 Bus Ratio (0 X)
This item helps you to set the frequency (bus ratio) of the throttled perform-
ance that will be initiated when the on die sensor goes from not hot to hot.
You may set the bus ration number from 0 to 255.
TM2 Bus VID (0.8375V)
This item helps you to set the voltage of the throttled performance that will be
initiated when the on die sensor goes from not hot to hot.
Limit CPUID MaxVal (Disabled)
This item limits the CPUID maximum value. Enable this item to install WinNT.
Leave this item at the default value for other OS.
Press to return to the Advanced BIOS Features screen.
