P.11
Indicators
No. Bottom components
(1) Power button
(2) System status indicator
• When the system is on, it lights up in green.
• When the system is in Sleep mode, it blinks up in green.
(3) Battery indicator
• When the battery is charging, it blinks up in orange.
• When the battery is fully charged, it lights up in orange.
• When the battery is in use, it lights up in green.
• When the battery is running low, it blinks in green.
(4) Hard disk/CD-ROM activity indicator
Flashes in green when the Netbook is accessing data in
the hard disk or/and externat CD-ROM.
(5) Wireless LAN (WLAN)/Bluetooth indicator
• When WLAN or Bluetooth is tuned on it lights up in green.
(1)
(5) (4) (3) (2)
Netbook User Manual
