E
E
x
x
t
t
e
e
r
r
n
n
a
a
l
l
C
C
R
R
T
T
D
D
i
i
s
s
p
p
l
l
a
a
y
y
You can hook up an external monitor through the 15-pin CRT connector. Configurations are available:
LCD only
CRT only
Simultaneous display of the LCD screen and CRT monitor
You can switch between these display configurations by pressing the key combination [Fn] + [F12].
A Tour of the Notebook’s Keyboard
The Notebook’s keyboard uses a standard QWERTY layout with the addition of special function keys and an
embedded numeric keypad for number intensive data entry. Your keyboard supports Windows by
incorporating the two Windows specific keys. With the two Windows keys you will be able to access and
take advantage of many of the timesaving features of Windows software.
The function keys (F1-F12) on the top row of the keyboard, serve different purposes and carry out different
tasks depending on the application you are running. The cursor (arrow) keys (which are all located in the
lower right corner of your keyboard) and the [PgUp], [PgDn], [Home] and [End] keys (which are located
along the right edge of the keyboard) allow you to move the active cursor of the computer to various
locations on the screen or within the document.
The embedded numeric keypad consists of 15 keys that make number intensive input more convenient. Like
the [Num Lock] key, these keys are labeled in blue on the keycaps. Numeric assignments are located at the
upper right of each key.
When the numeric keypad is engaged, the NumLock icon will appear in the System Window. The keypad is
activated by pressing the [Fn] + [NumLk] key. If an external keyboard is connected, pressing the NumLock
key on either the Notebook or external keyboard will enable/disable NumLock of both keyboards in unison.
To disable the Notebook numeric keypad while keeping the keypad on an external keyboard activated, use the
[Fn] + [NumLk] hot key on the Notebook keyboard.
24
