33
Using BIOS
SATA Configuration
Use this item to show the mode of serial SATA configuration options.
SATA Mode (IDE Mode)
Use this item to select SATA mode.
SATA Port 1~2 (Not Present)
This motherboard supports two SATA channel and each channel allows one SATA
device to be installed. Use these items to configure each device on the SATA channel.
Main Advanced Chipset Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Determines how SATA
controller(s) operate. SATA Configuration
SATA Mode IDE Mode
SATA Port1
Not Present
SATA Port2
Not Present
Press to return to the Advanced Menu page.
