Chapter 1
2
H87H3-M USER MANUAL
CPU
Specifications
• Intel
® H87 Chipset
Chipset
• Dual-channel DDR3 memory architecture
• 4 x 240-pin DDR3 DIMM sockets support up to 32 GB
• Supports DDR3 1600/1333 MHz SDRAM
Memory
• Supported by Intel
®
H87 Express Chipset
- 6 x Serial ATA 6Gb/s devices
- RAID 0, RAID 1, RAID 5, RAID 10 configuration
Expansion
Slots
Storage
• 1 x PS/2 mouse & keyboard Combo connector
• 1 x D-sub (VGA port)
• 1 x DVI port
• 1 x HDMI port
• 4 x USB 2.0 ports
• 1 x RJ45 LAN connector
• 2 x USB 3.0 ports
• 1 x Audio 8-ch jacks
Rear Panel I/O
LAN • Realtek RL8111G Gigabit Lan
• Realtek ALC892 8-Ch High Definition audio CODEC
-
Compliant with HD audio specification
Audio
• LGA1150 socket for Intel
®
4 th Generation Core TM Family
processors
• Supports CPU up to 84W, TDP up to 95W
• Supports Intel
®
Turbo Boost Technology
• Supports Intel
®
Hyper-Threading Technology
• Supports Intel
®
64 Architecture
• Supports Intel
®
Advanced Vector Extensions 2.0
• Supports Intel
®
Responsiveness Technologies
- Intel
®
Rapid Storage Technology 12
- Intel
®
Smart Response Technology *
- Intel
®
Rapid Start Technology *
Note: Please go to ECS website for the latest CPU support list.
Note: Please go to ECS website for the latest Memory support list.
AMD
CrossFireX
TM
Technology
• Supports AMD CrossFireX TM Technology
- T he PCIEX16_S1 (black color of PCIE x16 slot) supports PCI
Express Gen2 running at X4 mode
• 2 x PCI Express x16 slots (one PCI Express Gen3 x16 slot & one
PCI Express Gen2 x4 mode slot)
• 1 x PCI Express x1 Gen2 slot
• 1 x PCI v2.2 slot
* SSDS, multiple HDDs required.
Internal I/O
Connectors &
Headers • 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin ATX 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 1 x USB 3.0 header supports additional two USB 3.0 ports
