Chapter 3
H87H3-M4 USER MANUAL
63
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B. III (MB Intelligent BIOS III) Menu
 CPU OverClocking Configuration
Scroll to this item to view the following screen:
+/- : Change Opt.
Enter/Dbl Click : Select
 : Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
F4: Save & Exit

Main Advanced Chipset M.I.B. III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU OverClocking
Configuration M.I.B. III (MB Intelligent BIOS III)
CPU OverClocking Configuration
North Bridge Configuration
Memory Configuration
Over Voltage Configuration
Spread Spectrum Enabled
Intel(R) Core(TM) i7-4770K CPU @ 3.50GHz
Processor Speed
3500 MHz
Memory Frequency 1333 MHz
Total Memory 8192 MB (DDR3 )
Main Advanced Chipset M.I.B. III Boot Security Exit
Package Current Lock
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU Ratio (35)
This item allows you to control non turbo CPU ratio.
CPU Ratio 35
Package Current Lock Disabled
IA Core Current Maximum
Enhanced Intel SpeedStep Technology Enabled
Turbo Mode Enabled
Runtime Turbo Enable Disabled
Internal PLL Overvoltage Disabled
Boot Performance Mode Max Non-Turbo Perfor...
Package TDP Lock Enable Disabled
Long Duration Power Limit Override Maximum
Power Limit 1 Time(Second) 8
Power Limit 2 Switch Enabled
Short Duration Power Limit Overrid Maximum
1 Core Ratio Limit 39
2 Core Ratio Limit 39
3 Core Ratio Limit 38
4 Core Ratio Limit 37
Disable OverClocking Lock Enabled
