Davey PowerMaster ECO-SERIES - Manual (Page 4)

4
Technical Specifications:
Model PMECO
RPM
Eco Flow Speed – 1400
Mid Flow Speed – 2400
High Flow Speed – 2850
Enclosure Class (IP) 24
Insulation Class Class B130 Insulation
Voltage (V) 240 AC
Supply Frequency (Hz) 50
Run Current (A) 6.3
Motor Input Power (W / hp)
Eco Flow - 165w / 0.22 hp
Mid Flow – 677w / 0.91 hp
Hi Flow – 1109w / 1.49 hp
Motor Output Power (W / hp)
Eco Flow - 132w / 0.18 hp
Mid Flow – 542w / 0.72 hp
Hi Flow – 887w / 1.19 hp
Operating Limits:
Max Water temperature 50°C
Max Ambient temperature 55°C
Dimensions:
Model A B C D E
Mounting
Holes
Diam
Inlet /
Outlet
PVC
Net
Weight
(kg)
PMECO 577 330 250 305 246 10 *40/50 8.7
All dimensions in mm unless otherwise stated
*Suction & delivery accept 40mm PVC pipe on the ID & a 50mm fitting on the OD
