Tank installation, Step 9 – Burcam 506221S S.W. CAST IRON JET PUMP 3/4HP 115/230V User Manual
Page 8
To home’s plumbing distribution lineTo home’s plumbing distribution line
FOR INFORMATION TEL: 514.337.4415 FAX: 514.337.4029
TANK INSTALLATION
8
To home’s plumbing
distribution line
STEP 9
Connect the
pump discharge to the tank ‘T’
Snifter valve to
adjust air pressure
Pressure switch
1/4” connection
Pressure gauge
1/4” connection
Relief valve for pumps
with more than 75 PSI
of capacity
1/2” connection
Drain valve
1/2” connection
1” MNPT or 3/4” FNPT
connection
From well
