APPLICATION
This pump is designed for shallow well
installation for water level up to 25 feet.
CAPACITY AT 30 PSI:
5’ 800 US GPH
10’ 690 US GPH
15’ 625 US GPH
20’ 545 US GPH
25’ 480 US GPH
FEATURES
Easy to prime pump body.
Totally enclosed, fan cooled motor,
bearing to bearing. Built for a continuous use.
Full time connected run capacitor, to eliminate
starting wear vs regular motor.
Thermal and overload protection.
Noryl impeller, built-in injector
3/4HP, 115/230VAC, 60Hz, 9A, 18A
(when start) .
INSTALLATION STEPS
We recommend that you install your pump in a clean and dry location where
there is adequate room for servicing at a later date. Protection from freezing
temperatures and good ventilation should be considered as well, to provide the
pump an environment for long life. Locating the pump as close as possible to
the water source will reduce friction losses encountered in the suction pipe.
Friction losses in the suction pipe must be taken into consideration when the
horizontal offset is greater than 50 feet. The suction pipes should be increased
from 1” to 1 1/4”. This will reduce friction losses and allow the pump to give
maximum performance.
A new well should be checked to determine that it is free from sand. Sand will
damage the seal and the impeller. Have your well driller clean the well before
your installation.
Never run the pump dry. Damage to the seal may occur. Fill pump body and
suction pipe with water before turning on the power.
THE RUN OF HORIZONTAL PIPE FROM THE TOP OF
YOUR WELL INTO THE HOUSE, WHERE YOUR PUMP
WILL BE LOCATED, MUST BE INSTALLED IN A TRENCH,
BELOW THE FROST LEVEL OF YOUR AREA.
STEP 1
FRICTION LOSS IN
PIPE NOT INCLUDED
