- 3 -
Integral Sounder Tones (DIP Switch No. SW1-SW3)
The Alert Point Lite has seven different selectable alarm tones ranging from 95 to 102dB.
Sounder Timer Options (DIP Switch No. SW5 & SW6)
Four alarm conditions are available and can be selected by changing the DIP switch settings. These are:
30 seconds, 3 minutes, 20 minutes or continuous.
If any duration other than “continuous” is used, the alarm will silence after the selected time has elapsed.
This alarm will NOT be able to be reactivated until the unit is reset with the reset key.
Key Switch – Reset (DIP Switch No. SW7)
This allows the user greater control if misuse becomes a major factor.
SW7 position - ON: The Alert Point Lite will fully reset after activation when using the reset key.
SW7 position - OFF: Even if the Alert Point Lite is reset after activation using the reset key, all sounders
will continue to run until the unit is reset using the master key switch.
DIP Switch Settings
Important: Changes to any DIP Switch settings will only take effect after the Alert Point Lite has been
reset using the master key switch (turn “OFF” then back “ON”).
FEATURES DIP SWITCH SETTING ACTION
Integral
Sounder Alarm
Tone SW1 SW2 SW3 Tone Sound Pattern
OFF OFF OFF 1 800Hz - 970Hz (Sweep)
ON OFF OFF 2 800Hz - 970Hz (Sweep)
OFF ON OFF 3 988Hz / 250ms - 645Hz / 250ms (Alternating)
ON ON OFF 4 670Hz / 250ms - 845Hz / 370ms (Alternating)
OFF OFF ON 5 800Hz - 970Hz in 350ms (Sweep)
ON OFF ON 6 2400Hz - 2850Hz in 110ms (Sweep)
OFF ON ON 7 2400Hz - 2850Hz in 330ms (Sweep)
ON ON ON 8 Not implemented
SW5 SW6 Sounder Duration
OFF OFF Sounders run continuously (until manually reset)
ON OFF Sounders switch off automatically after 30 seconds
OFF ON Sounders switch off automatically after 3 minutes
ON ON Sounders switch off automatically after 20 minutes
Alert Point Lite returns to “standby” condition after resetting
with reset key.
Alert Point Lite latches in “alarm” condition until it is
manually reset using the master key switch.
The Alert Point Lite expects to be connected to another Alert
Point Lite, otherwise a warning beep is emitted.
No fault will be indicated if an Alert Point Lite is not connected
to another Alerrt Point Lite, it is not looking for a connection.
SW4 ON Not used
SW4 OFF Not used
Sounder
Duration Timer
Reset
Networking
the Alert Point
Lite
Factory setting
SW7 ON
SW7 OFF
SW8 ON
SW8 OFF
Programmable Features
